Intel Core Ultra 5 245KF - 14-Core (6P+8E) up to 5.2GHz Boost - LGA1851, DDR5, Unlocked (Tray), No iGPU
14-core Intel Core Ultra 5 245KF (6P+8E) up to 5.2GHz boost, DDR5 dual-channel (up to 192GB), Intel AI Boost NPU (up to 22 TOPs). Tray package, unlocked, no integrated GPU.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Core Ultra 5 |
|---|---|
| CPU (Processors) - Socket | LGA 1851 (Socket V1) |
| CPU (Processors) - Cores | 14 |
| CPU (Processors) - Integrated Graphics | None |
| CPU (Processors) - Memory Support | DDR5 |
| CPU (Processors) - PCIe Version | PCIe 5.0 |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
Intel Core Ultra 5 245KF. Processor family: Intel Core Ultra 5. Processor socket: LGA 1851 (Socket V1). Package type: Tray. Neural processor unit (NPU): Intel AI Boost. AI software frameworks supported by NPU: DirectML. OpenVINO. Windows ML. ONNX RT. WebNN. Total processor performance up to: 22 TOPs. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR5-SDRAM. Market segment: Desktop. Use conditions: PC/Client/Tablet. PCI Express slots version: 4.0. 5.0. L2 cache: 26624 KB. Maximum internal memory: 192 GB
| Processor manufacturer | Intel |
| Processor generation | Intel Core Ultra (Series 2) |
| Processor model | 245KF |
| Processor family | Intel Core Ultra 5 |
| Processor cores | 14 |
| Processor socket | LGA 1851 (Socket V1) |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Efficient cores | 8 |
| Processor boost frequency | 5.2 GHz |
| Performance-core boost frequency | 5.2 GHz |
| Performance-core base frequency | 4.2 GHz |
| Efficient-core boost frequency | 4.6 GHz |
| Efficient-core base frequency | 3.6 GHz |
| Processor cache | 24 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 125 W |
| Maximum turbo power | 159 W |
| AI software frameworks supported by CPU | DirectML. OpenVINO. Windows ML. ONNX RT. WebNN |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Processor codename | Arrow Lake |
| Processor ARK ID | 241066 |
| Neural processor unit (NPU) | Intel AI Boost |
| Feature | Intel® Standard Manageability (ISM) |
| AI software frameworks supported by NPU | DirectML. OpenVINO. Windows ML. ONNX RT. WebNN |
| Total processor performance up to | 22 TOPs |
| NPU performance up to | 13 TOPs |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 6400 MHz |
| Memory channels | Dual-channel |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 24 |
| PCI Express slots version | 4.0. 5.0 |
| Supported instruction sets | AVX 2.0. SSE4.1. SSE4.2 |
| Scalability | 1S |
| Thermal solution specification | PCG 2020A |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Maximum operating temperature | 105 °C |
| Harmonized System (HS) code | 8542310050 |
| Launch date | Q4'24 |
| Status | Launched |
| Memory speed (max) | 6400 MHz |
| L2 cache | 26624 KB |
| Maximum internal memory | 192 GB |
