Intel Core i7-13700K - 13th Gen LGA1700 CPU, 16 cores/24 threads, up to 5.4GHz, DDR4/DDR5, Intel UHD 770
Intel Core i7-13700K (13th Gen) unlocked desktop CPU — LGA1700, 16 cores (8P+8E)/24 threads, up to 5.4 GHz, DDR4/DDR5 support, Intel UHD 770 graphics. Tray (no cooler).
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Series / Family | Intel Core i7 |
|---|---|
| CPU (Processors) - Generation / Code name | Intel Raptor Lake |
| CPU (Processors) - Socket | LGA1700 |
| CPU (Processors) - Cores | 16 |
| CPU (Processors) - Threads | 24 |
| CPU (Processors) - TDP | 120-125 W |
| CPU (Processors) - Integrated Graphics | Intel UHD |
| CPU (Processors) - Memory Support | DDR5 |
| CPU (Processors) - PCIe Version | PCIe 5.0 |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
Intel Core i7-13700K. Processor family: Intel® Core™ i7. Processor socket: LGA 1700. Package type: Tray. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770. On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1. On-board graphics card base frequency: 300 MHz. Market segment: Desktop. Use conditions: PC/Client/Tablet. Workstation. PCI Express slots version: 4.0. 5.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.4 GHz
| Processor manufacturer | Intel |
| Processor generation | 13th gen Intel® Core™ i7 |
| Processor model | i7-13700K |
| Processor family | Intel® Core™ i7 |
| Processor cores | 16 |
| Processor socket | LGA 1700 |
| Processor threads | 24 |
| Processor operating modes | 64-bit |
| Performance cores | 8 |
| Efficient cores | 8 |
| Processor boost frequency | 5.4 GHz |
| Performance-core boost frequency | 5.3 GHz |
| Performance-core base frequency | 3.4 GHz |
| Efficient-core boost frequency | 4.2 GHz |
| Efficient-core base frequency | 2.5 GHz |
| Processor cache | 30 MB |
| Processor cache type | Smart Cache |
| Package type | Tray |
| Processor base power | 125 W |
| Maximum turbo power | 253 W |
| Stepping | B0 |
| Bus type | DMI4 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 230500 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Feature | Intel vPro® Essentials Platform Eligibility |
| Memory bandwidth (max) | 89.6 GB/s |
| On-board graphics card model | Intel UHD Graphics 770 |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b. DisplayPort 1.4a. HDMI 2.1 |
| On-board graphics card base frequency | 300 MHz |
| On-board graphics card dynamic frequency (max) | 1600 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card DirectX version | 12.0 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 5120 x 3200 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2160 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 120 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card ID | 0xA780 |
| Discrete graphics card model | Not available |
| Number of execution units | 32 |
| Multi-Format Codec Engines | 2 |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet. Workstation |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0. 5.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | SSE4.1. SSE4.2. AVX 2.0 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.4 GHz |
| Tjunction | 100 °C |
| Target market | Gaming. Content Creation |
| OpenCL version | 3.0 |
| Launch date | Q4'22 |
| Status | Launched |
| Harmonized System (HS) code | 8542310001 |
| L2 cache | 24576 KB |
| Maximum internal memory | 192 GB |
| Graphics output | eDP 1.4b. DP 1.4a. HDMI 2.1 |
