Intel Xeon Gold 6154 - 18C/36T 3.0GHz (3.7GHz Turbo) LGA3647 Server CPU - Tray, 200W TDP
Intel Xeon Gold 6154 server processor — 18 cores / 36 threads, 3.0 GHz base (3.7 GHz turbo), LGA3647 tray SKU, Skylake-SP, DDR4 hexa-channel support, 200 W TDP, up to 768 GB RAM
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
| CPU (Processors) - Integrated Graphics | None |
|---|---|
| CPU (Processors) - Memory Support | DDR4 |
| CPU (Processors) - PCIe Version | PCIe 3.0 |
| CPU (Processors) - Unlocked/Overclockable | No |
| CPU (Processors) - Cooler Included | No |
Intel Xeon 6154. Processor family: Intel® Xeon® Gold. Processor socket: LGA 3647 (Socket P). Processor lithography: 14 nm. Memory channels: Hexa-channel. Maximum internal memory supported by processor: 768 GB. Memory types supported by processor: DDR4-SDRAM. Market segment: Server. Supported instruction sets: SSE4.2. AVX. AVX 2.0. AVX-512. Scalability: S4S. Processor package size: 76mm x 56.5mm. Maximum internal memory: 768 GB. Maximum internal memory: 786432 MB
| Processor manufacturer | Intel |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 6154 |
| Processor base frequency | 3 GHz |
| Processor family | Intel® Xeon® Gold |
| Processor cores | 18 |
| Processor socket | LGA 3647 (Socket P) |
| Component for | Server/workstation |
| Processor lithography | 14 nm |
| Processor threads | 36 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.7 GHz |
| Processor cache | 25344 KB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 200 W |
| Package type | Tray |
| Processor codename | Skylake |
| Processor code | SR3J5 |
| Processor ARK ID | 120495 |
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory channels | Hexa-channel |
| Feature | Intel® vPro™ Platform Eligibility |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | SSE4.2. AVX. AVX 2.0. AVX-512 |
| Scalability | S4S |
| PCI Express CEM revision | 3.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel TSX-NI version | 1.00 |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Tcase | 82 °C |
| Launch date | Q3'17 |
| Product type | Processor |
| Status | Launched |
| Maximum memory | 768 GB |
| Processor brand name | Intel Xeon GoldIntel Xeon Gold Processor |
| Supported memory types | DDR4-SDRAM |
| Last change | 63903513 |
| Product family | Intel Xeon Processors |
| Intel® Speed Shift Technology version | 1.00 |
| Intel® Run Sure Technology version | 1.00 |
| Intel® Volume Management Device (VMD) version | 1.00 |
| Memory speed (max) | 2666 MHz |
| Mode-based Execute Control (MBE) version | 1.00 |
| Number of UPI links | 3 |
| Harmonized System (HS) code | 8542310001 |
| Processor package size | 76mm x 56.5mm |
| Maximum internal memory | 786432 MB |
