Intel Core i9-13900F - 13th Gen (Raptor Lake) - 24 Cores (8P+16E), 5.6GHz Turbo, LGA1700, DDR4/DDR5
Intel Core i9-13900F, 13th Gen Raptor Lake: 24 cores (8P+16E) / 32 threads, up to 5.6 GHz, LGA1700, supports DDR4 & DDR5, PCIe 5.0 — no integrated GPU.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Unlocked/Overclockable | No |
|---|
Intel Core i9-13900F. Processor family: Intel® Core™ i9. Processor socket: LGA 1700. Package type: Box. Memory channels: Dual-channel. Maximum internal memory supported by processor: 192 GB. Memory types supported by processor: DDR4-SDRAM. DDR5-SDRAM. Market segment: Desktop. Use conditions: PC/Client/Tablet. PCI Express slots version: 5.0. 4.0. Intel® Turbo Boost Max Technology 3.0 frequency: 5.5 GHz. Intel® Thermal Velocity Boost Frequency: 5.6 GHz. Processor package size: 45 x 37.5 mm
| Processor manufacturer | Intel |
| Processor generation | 13th gen Intel® Core™ i9 |
| Processor model | i9-13900F |
| Processor family | Intel® Core™ i9 |
| Processor cores | 24 |
| Processor socket | LGA 1700 |
| Processor threads | 32 |
| Processor operating modes | 64-bit |
| Performance cores | 8 |
| Efficient cores | 16 |
| Processor boost frequency | 5.6 GHz |
| Performance-core boost frequency | 5.2 GHz |
| Performance-core base frequency | 2 GHz |
| Efficient-core boost frequency | 4.2 GHz |
| Efficient-core base frequency | 1.5 GHz |
| Processor cache | 36 MB |
| Processor cache type | Smart Cache |
| Package type | Box |
| Feature | Intel® Standard Manageability (ISM) |
| Processor base power | 65 W |
| Maximum turbo power | 219 W |
| Bus type | DMI4 |
| Maximum number of DMI lanes | 8 |
| Memory bandwidth supported by processor (max) | 89.6 GB/s |
| Processor codename | Raptor Lake |
| Processor ARK ID | 230502 |
| Maximum internal memory supported by processor | 192 GB |
| Memory types supported by processor | DDR4-SDRAM. DDR5-SDRAM |
| Memory channels | Dual-channel |
| Memory bandwidth (max) | 89.6 GB/s |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
| Market segment | Desktop |
| Use conditions | PC/Client/Tablet |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 5.0. 4.0 |
| PCI Express configurations | 1x16+1x4. 2x8+1x4 |
| Supported instruction sets | SSE4.1. SSE4.2. AVX 2.0 |
| Scalability | 1S |
| CPU configuration (max) | 1 |
| Direct Media Interface (DMI) Revision | 4.0 |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | 740.17B1 |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Max Technology 3.0 frequency | 5.5 GHz |
| Intel® Thermal Velocity Boost Frequency | 5.6 GHz |
| Tjunction | 100 °C |
| Harmonized System (HS) code | 8542310001 |
| Target market | Gaming. Content Creation |
| Launch date | Q1'23 |
| Status | Launched |
| Processor package size | 45 x 37.5 mm |
| L2 cache | 32768 KB |
| Maximum internal memory | 192 GB |
