ASRock Barebone 1U Single Sockel 1700 1U1G-W680 2L2T
Asrock 1U1G-W680/2L2T. Intel W680. LGA 1700. Intel. DDR5-SDRAM. 192 GB. 1.1 V
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Asrock 1U1G-W680/2L2T. Motherboard Chipsatz: Intel W680. Prozessorsockel: LGA 1700. Prozessorhersteller: Intel. Unterstützte Arbeitsspeicher: DDR5-SDRAM. RAM-Speicher maximal: 192 GB. Speicherspannung: 1.1 V. unterstützte Speicherlaufwerksgrößen: 2.5.M.2. Unterstützte Speicherlaufwerke: HDD & SSD. Unterstützte Speicherlaufwerk-Schnittstellen: PCI Express 3.0. Serial ATA III. Eingebautes Grafikkartenmodell: Aspeed AST2600. Ethernet Schnittstellen Typ: 10 Gigabit Ethernet. Gigabit Ethernet. LAN-Controller: Intel I210. Intel® X710
| Motherboard Chipsatz | Intel W680 |
| Prozessorsockel | LGA 1700 |
| Prozessorhersteller | Intel |
| Anzahl unterstützter Prozessoren | 1 |
| Zahl der DIMM Slots | 4 |
| Unterstützte Arbeitsspeicher | DDR5-SDRAM |
| RAM-Speicher maximal | 192 GB |
| Speicherspannung | 1.1 V |
| Anzahl der unterstützten Speicherlaufwerke | 5 |
| Feature | Hot-Swap-Netzteil |
| Anzahl der 2.5" Erweiterungseinschübe | 4 |
| unterstützte Speicherlaufwerksgrößen | 2.5.M.2 |
| Unterstützte Speicherlaufwerke | HDD & SSD |
| Unterstützte Speicherlaufwerk-Schnittstellen | PCI Express 3.0. Serial ATA III |
| SSD-Formfaktor | M.2 |
| Eingebautes Grafikkartenmodell | Aspeed AST2600 |
| Ethernet Schnittstellen Typ | 10 Gigabit Ethernet. Gigabit Ethernet |
| LAN-Controller | Intel I210. Intel® X710 |
| Anzahl USB 2.0 Anschlüsse | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 4 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 4 |
| Anzahl HDMI-Anschlüsse | 1 |
| Anzahl DisplayPort Anschlüsse | 1 |
| Anzahl VGA (D-Sub) Anschlüsse | 1 |
| Anzahl COM-Anschlüsse | 1 |
| PCI-Express-Slots-Version | 4.0 |
| PCI Express x16-Steckplätze (Gen 4.x) | 1 |
| BIOS-Typ | AMI |
| ACPI-Version | 6.4 |
| Gehäusetyp | Rack (1U) |
| Produktfarbe | Grau |
| LED-Anzeigen | Aktivität. Störung. LAN. Leistung. Unit Identification (UID) |
| Stromversorgung | 800 W |
| Anzahl der Haupt-Netzteile | 2 |
| Anzahl der unterstützten Hot-Swap-Netzteile | 1 |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| 80 Plus Zertifizierung | 80 PLUS Platinum |
| Betriebstemperatur | 10 - 35 °C |
| Temperaturbereich bei Lagerung | -40 - 70 °C |
| Relative Luftfeuchtigkeit in Betrieb | 20 - 90% |
| Breite | 650 mm |
| Tiefe | 438 mm |
| Höhe | 43.5 mm |
