Antenne panel direktional dual-polarization 5GHz
LevelOne WAN-9151. 15 dBi. 5.1 ~ 5.9 GHz. IEEE 802.11a. IEEE 802.11n. 50 Ohm. 22°. 15°
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne WAN-9151. Antenne Zunahmeniveau (max): 15 dBi. Frequenzband: 5.1 ~ 5.9 GHz. Netzstandard: IEEE 802.11a. IEEE 802.11n. Antennentyp: Richtantenne. Antenne Steckertyp: N-Typ. Polarisation: Duale Polarisation. Breite: 137.5 mm. Tiefe: 162.5 mm. Höhe: 16 mm. Verpackungsbreite: 161 mm. Verpackungstiefe: 218 mm. Verpackungshöhe: 74 mm. Ursprungsland: Taiwan. Breite des Versandkartons: 370 mm. Länge des Versandkartons: 450 mm
| Frequenzband | 5.1 ~ 5.9 GHz |
| Netzstandard | IEEE 802.11a. IEEE 802.11n |
| Impedanz | 50 Ohm |
| Horizontale Lichtstrahlbreite | 22° |
| Vertikale Lichtstrahlbreite | 15° |
| Antenne Zunahmeniveau (max) | 15 dBi |
| Antennentyp | Richtantenne |
| Antenne Steckertyp | N-Typ |
| Polarisation | Duale Polarisation |
| Spannung Stellung-Welle Verhältnis (VSWR) | 2.0 |
| Produktfarbe | Grau |
| Schutzfunktion | Staubresistent. Snow resistant. Wasserfest |
| Überlebens-Windgeschwindigkeit | 180 km/h |
| Zweck | Innen & Außen |
| Maximaler Kabel-Verlust mit Steckern | -10 dB |
| Betriebstemperatur | -30 - 60 °C |
| Relative Luftfeuchtigkeit in Betrieb | 0 - 95% |
| Breite | 137.5 mm |
| Tiefe | 162.5 mm |
| Höhe | 16 mm |
| Gewicht | 208 g |
| Verpackungsbreite | 161 mm |
| Verpackungstiefe | 218 mm |
| Verpackungshöhe | 74 mm |
| Paketgewicht | 726 g |
| Verpackungsart | Box |
| Feature | Schnellinstallationsanleitung |
| Warentarifnummer (HS) | 85177100 |
| Ursprungsland | Taiwan |
| Breite des Versandkartons | 370 mm |
| Länge des Versandkartons | 450 mm |
| Höhe des Versandkartons | 340 mm |
| Gewicht Versandkarton | 15.5 kg |
| Anzahl Produkte pro Versandkarton | 20 Stück(e) |
