Switch 8x FE IFP-0801 4xFE 126W 4xPoE
LevelOne IFP-0801. Fast Ethernet (10/100). Vollduplex. Power over Ethernet (PoE). Wandmontage
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LevelOne IFP-0801. Basic Switching RJ-45 Ethernet Ports-Typ: Fast Ethernet (10/100). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 12. Vollduplex. MAC-Adressentabelle: 1000 Eintragungen. Routing-/Switching-Kapazität: 1.6 Gbit/s. Netzstandard: IEEE 802.3. IEEE 802.3af. IEEE 802.3at. IEEE 802.3u. IEEE 802.3x. Power over Ethernet (PoE). Wandmontage
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 12 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Fast Ethernet (10/100) |
| Netzstandard | IEEE 802.3. IEEE 802.3af. IEEE 802.3at. IEEE 802.3u. IEEE 802.3x |
| Kupfer Ethernet Verkabelungstechnologie | 10BASE-T. 100BASE-TX |
| Feature | DIN-Schiene enthalten |
| Routing-/Switching-Kapazität | 1.6 Gbit/s |
| MAC-Adressentabelle | 1000 Eintragungen |
| Datenpaket-Pufferspeicher | 1 MB |
| Produktfarbe | Schwarz |
| LED-Anzeigen | Link. Leistung. Status |
| Sicherheit | IEC EN60950-1 |
| Mittlere Betriebsdauer zwischen Ausfällen (MTBF) | 510304 h |
| Stromverbrauch (Standardbetrieb) | 5.76 W |
| Anzahl Power over Ethernet plus (PoE+) Anschlüsse | 4 |
| Power over Ethernet (PoE) Spannungsbereich | 44 - 56 V |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 126 W |
| Betriebstemperatur | -40 - 75 °C |
| Relative Luftfeuchtigkeit in Betrieb | 5 - 95% |
| Breite | 105 mm |
| Tiefe | 36.2 mm |
| Höhe | 142 mm |
| Gewicht | 525 g |
| Verpackungsart | Box |
| Verpackungsbreite | 165 mm |
| Verpackungstiefe | 65 mm |
| Verpackungshöhe | 215 mm |
| Paketgewicht | 730 g |
| Zertifizierung | EMI: FCC Part 15 Subpart B Class ACE EN 55022 Class AEMC: EN55022. EN55024EN50155/EN60068-2-6EN50155/EN60068-2-27EN50155/EN60068-2-32 |
| Ursprungsland | Taiwan |
| Breite des Versandkartons | 350 mm |
| Länge des Versandkartons | 240 mm |
| Höhe des Versandkartons | 570 mm |
| Warentarifnummer (HS) | 85176990 |
| Gewicht Versandkarton | 12.6 kg |
| Anzahl Produkte pro Versandkarton | 16 Stück(e) |
