2500W FSP CANNON PRO 2500 80+ Platin ATX 3.1
FSP CANNON PRO 2500W Netzteil ATX ATX3.1 Schwarz. 2500 W. 200 - 240 V. 50/60 Hz. 15 - 12 A. Aktiv. 125 W
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
FSP CANNON PRO 2500W Netzteil ATX ATX3.1 Schwarz. Gesamtleistung: 2500 W. AC Eingangsspannung: 200 - 240 V. AC Eingangsfrequenz: 50/60 Hz. Motherboard Anschlussstecker: 20+4 pin ATX. SATA-Netzkabellänge: 965 mm. Periphere (Molex) Netzkabellänge: 965 mm. Zweck: PC. Stromversorgungseinheit (PSU) Formfaktor: ATX. 80 Plus Zertifizierung: 80 PLUS Platinum. Produktfarbe: Schwarz. Lüfterdurchmesser: 13.5 cm. Anzahl Lüfter: 1 Lüfter. Breite: 150 mm. Tiefe: 200 mm. Höhe: 86 mm
| Gesamtleistung | 2500 W |
| AC Eingangsspannung | 200 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Eingangsstrom | 15 - 12 A |
| Leistungsfaktor | 0.9 |
| Leistungsfaktorkorrekturfilter (PFC) | Aktiv |
| Kombinierter Strom (+3.3V) | 125 W |
| Kombinierter Strom (+12V) | 2499.6 W |
| Kombinierter Strom (+5V) | 125 W |
| Kombinierter Strom (-12V) | 3.6 W |
| Kombinierter Strom (+5Vsb) | 20 W |
| Max. Ausgangsstrom (+3.3V) | 25 A |
| Max. Ausgangsstrom (+12V) | 208.3 A |
| Max Ausgangsstrom (+5V) | 25 A |
| Max. Ausgangsstrom (-12V) | 0.3 A |
| Max. Ausgangsstrom (+5Vsb) | 4 A |
| Effizienz | 94% |
| Energieschutzeigenschaften | No load operation. Überstrom. Überlastung. Überspannung. Kurzschluß. Überspannung und Zustrom. Unter Temperatur. Unterspannung |
| Motherboard Anschlussstecker | 20+4 pin ATX |
| Anzahl SATA Stromstecker | 8 |
| SATA-Netzkabellänge | 965 mm |
| Anzahl der SATA-Stromkabel | 2 |
| Anzahl Molex Anschlüsse 4pin | 4 |
| Periphere (Molex) Netzkabellänge | 965 mm |
| Anzahl PCI Express Stromstecker 6+2pin | 3 |
| Anzahl PCI Express Stromstecker 8pin | 8 |
| Feature | Ein-/Ausschalter |
| Kabeltyp | Vollständig modular |
| 80 Plus Zertifizierung | 80 PLUS Platinum |
| Zweck | PC |
| Stromversorgungseinheit (PSU) Formfaktor | ATX |
| ATX-Version | 3.1 |
| Lagertyp | FDB |
| Produktfarbe | Schwarz |
| Lüfterdurchmesser | 13.5 cm |
| Anzahl Lüfter | 1 Lüfter |
| Lüfterplatzierung | Oben |
| Breite | 150 mm |
| Tiefe | 200 mm |
| Höhe | 86 mm |
