XS-3526YUP
LANCOM XS-3526YUP. Managed. L2/L3. 2.5G Ethernet (100/1000/2500). Power over Ethernet (PoE). Rack-Einbau. 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LANCOM XS-3526YUP. Switch-Typ: Managed. Switch-Ebene: L2/L3. Basic Switching RJ-45 Ethernet Ports-Typ: 2.5G Ethernet (100/1000/2500). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 24. Konsolen-Port: RJ-45. MAC-Adressentabelle: 32000 Eintragungen. Netzstandard: IEEE 802.1D. IEEE 802.1s. IEEE 802.1w. IEEE 802.3af. IEEE 802.3at. IEEE 802.3bt. Netzstecker: AC-Eingangsbuchse. Power over Ethernet (PoE). Rack-Einbau. Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L2/L3 |
| Feature | Betriebsanleitung |
| MIB Unterstützung | MIB II. Bridge MIB. Interface MIB. SMON MIB. IGMP MIB |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 24 |
| Basic Switching RJ-45 Ethernet Ports-Typ | 2.5G Ethernet (100/1000/2500) |
| Anzahl Gigabit Ethernet (Kupfer) Anschlüsse | 16 |
| Anzahl 10G Ethernet (Kupfer)-Ports | 8 |
| Konsolen-Port | RJ-45 |
| Anzahl SFP28-Ports | 2 |
| Netzstecker | AC-Eingangsbuchse |
| Netzstandard | IEEE 802.1D. IEEE 802.1s. IEEE 802.1w. IEEE 802.3af. IEEE 802.3at. IEEE 802.3bt |
| unterstütze Kabeltypen | Cat6. Cat7 |
| Virtuelle LAN-Funktionen | Voice VLAN |
| Anzahl der VLANs | 4093 |
| Durchsatz | 292 Gbit/s |
| MAC-Adressentabelle | 32000 Eintragungen |
| Jumbo-Frames | 10240 |
| Datenpaket-Pufferspeicher | 4 MB |
| DHCP-Funktionen | DHCP server |
| IGMP-Einträge | 1024 |
| Autentifizierungstyp | IEEE 802.1x. RADIUS. TACACS+ |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| Gehäusematerial | Metall |
| Anzahl Lüfter | 1 Lüfter |
| Geräuschpegel | 48 dB |
| Energiequelle | AC |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Stromverbrauch (max.) | 865 W |
| Anzahl Power over Ethernet (PoE) Anschlüsse | 8 |
| Betriebstemperatur | 0 - 40 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Wärmeableitung | 375 BTU/h |
| Breite | 442 mm |
| Tiefe | 375 mm |
| Höhe | 44 mm |
| Gewicht | 4.9 kg |
| Verpackungsbreite | 480 mm |
| Verpackungstiefe | 570 mm |
| Verpackungshöhe | 100 mm |
| Paketgewicht | 5.22 kg |
| Zolltarifnummer (TARIC) | 85176200 |
| Ursprungsland | Taiwan |
