Teltonika · Switch · SWM282 · 24 Port Gigabit managed PoE L2+ Switch. 4x SFP. 19
Teltonika SWM282. Managed. L2+. Gigabit Ethernet (10/100/1000). Power over Ethernet (PoE). Rack-Einbau
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
Teltonika SWM282. Switch-Typ: Managed. Switch-Ebene: L2+. Basic Switching RJ-45 Ethernet Ports-Typ: Gigabit Ethernet (10/100/1000). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 24. MAC-Adressentabelle: 8000 Eintragungen. Routing-/Switching-Kapazität: 56 Gbit/s. Netzstandard: IEEE 802.3i. IEEE 802.3u. IEEE 802.3ab. IEEE 802.3x. IEEE 802.3az. IEEE 802.1x. IEEE 802.3af. IEEE.... Netzstecker: AC-Eingangsbuchse. Power over Ethernet (PoE). Rack-Einbau
| Switch-Typ | Managed |
| Switch-Ebene | L2+ |
| Feature | Schnellstartübersicht |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 24 |
| Basic Switching RJ-45 Ethernet Ports-Typ | Gigabit Ethernet (10/100/1000) |
| Menge SFP-Modul-Steckplätze | 4 |
| Netzstecker | AC-Eingangsbuchse |
| Netzstandard | IEEE 802.3i. IEEE 802.3u. IEEE 802.3ab. IEEE 802.3x. IEEE 802.3az. IEEE 802.1x. IEEE 802.3af. IEEE 802.3at. IEEE 802.1p. IEEE 802.1Q |
| Ethernet LAN Datentransferraten | 10.100.1000 Mbit/s |
| Routing-/Switching-Kapazität | 56 Gbit/s |
| Transferrate | 83.33 Mpps |
| MAC-Adressentabelle | 8000 Eintragungen |
| Jumbo-Frames | 10000 |
| Datenpaket-Pufferspeicher | 0.512 MB |
| DHCP-Funktionen | DHCP server. DHCP client. DHCPv6 client |
| Autentifizierungstyp | RADIUS. TACACS+ |
| Warteschleifenplanungs-Algorithmen | SP. WFQ. Weighted Round Robin (WRR) |
| Produktfarbe | Schwarz |
| Gehäusematerial | Aluminium |
| Internationale Schutzart (IP-Code) | IP30 |
| Prozessortaktfrequenz | 500 MHz |
| Speichertyp | DDR3-SDRAM |
| Speicherkapazität | 128 MB |
| Flash-Speicher | 16 MB |
| Energiequelle | AC |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Stromverbrauch (max.) | 330 W |
| Power-over-Ethernet (PoE)-Typ unterstützt | Active PoE. PoE+ |
| Power over Ethernet (PoE) Modi | Alternative A |
| Anzahl Power over Ethernet plus (PoE+) Anschlüsse | 24 |
| Power over Ethernet (PoE) Leistung pro Anschluss | 30 W |
| Gesamtleistung Power over Ethernet (PoE) | 300 W |
| Betriebstemperatur | 0 - 50 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Breite | 483 mm |
| Tiefe | 234 mm |
| Höhe | 44 mm |
| Gewicht | 2.29 kg |
| Verpackungsart | Box |
| Konformitätsbescheinigungen | CE. UKCA. CB. RCM. Eidgenössische Kommunikationskommission (FCC). Industry Canada (IC) |
