Gigabyte B860M E (1851) (D)
GIGABYTE B860M E Mainboard - Intel Core Ultra Series CPUs. 4+1+2 Phasen VRM. bis zu 8800MHz DDR5 (O.C). 2xPCIe 4.0 M.2. 1GbE LAN. USB 3.2 Gen 1. Intel. LGA 1851 (Socket V1). Intel Core Ultra (Series 2). LGA 1851. DDR5-SDRAM. 128 GB
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
GIGABYTE B860M E Mainboard - Intel Core Ultra Series CPUs. 4+1+2 Phasen VRM. bis zu 8800MHz DDR5 (O.C). 2xPCIe 4.0 M.2. 1GbE LAN. USB 3.2 Gen 1. Prozessorhersteller: Intel. Prozessorsockel: LGA 1851 (Socket V1). Kompatible Prozessoren: Intel Core Ultra (Series 2). Unterstützte Arbeitsspeicher: DDR5-SDRAM. RAM-Speicher maximal: 128 GB. Arbeitsspeicher Typ: DIMM. Unterstützte Speicherlaufwerk-Schnittstellen: M.2. PCI Express 4.0. SATA III. Unterstützte Speicherlaufwerke: HDD & SSD. RAID Level: 0. 1. 5. 10. Maximale Auflösung: 4096 x 2160 Pixel. Ethernet Schnittstellen Typ: Gigabit Ethernet. LAN-Controller: Realtek RTL8111H
| Prozessorhersteller | Intel |
| Prozessorsockel | LGA 1851 (Socket V1) |
| Kompatible Prozessoren | Intel Core Ultra (Series 2) |
| Unterstützte Prozessorsteckplätze | LGA 1851 |
| Unterstützte Arbeitsspeicher | DDR5-SDRAM |
| Anzahl der Speichersteckplätze | 2 |
| Arbeitsspeicher Typ | DIMM |
| Speicherkanäle | Zweikanalig |
| ECC-Kompatibilität | ECC & Nicht-ECC |
| Unterstützte Arbeitsspeichergeschwindigkeit | 8800.8600.8400.8266.8200.8000.7950.7900.7800.7600.7400.7200.7000.6800.6600.6400.5600 MHz |
| Unterstützte Speichertaktrate (max.) | 8800 MHz |
| RAM-Speicher maximal | 128 GB |
| Feature | Schrauben enthalten |
| Maximaler interner Speicher pro Steckplatz | 64 GB |
| Unterstützte Speicherlaufwerke | HDD & SSD |
| Unterstützte Speicherlaufwerk-Schnittstellen | M.2. PCI Express 4.0. SATA III |
| Maximale unterstützte Anzahl der HDD | 4 |
| Anzahl der unterstützten Speicherlaufwerke | 6 |
| RAID Level | 0. 1. 5. 10 |
| Parallele Verarbeitungstechnologie | Nicht unterstützt |
| Maximale Auflösung | 4096 x 2160 Pixel |
| HDCP-Version | 2.3 |
| DirectX-Version | 12.0 |
| Anzahl USB 2.0 Schnittstellen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anschlüsse | 1 |
| SATA III Anschlüsse | 4 |
| Anzahl der CPU-Lüfteranschlüsse | 2 |
| Zahl der Chassisventilatorstecker | 1 |
| Anzahl der EPS-Stromanschlüsse (4--polig) | 1 |
| Serielle Port-Headers | 1 |
| Anzahl der Wasserpumpenanschlüsse | 2 |
| Anzahl der RGB-LED-Stiftleisten | 2 |
| Anzahl USB 2.0 Anschlüsse | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ A | 4 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| Anzahl PS/2 Anschlüsse | 1 |
| Anzahl HDMI-Anschlüsse | 1 |
| HDMI-Version | 2.1 |
| Anzahl DisplayPort Anschlüsse | 1 |
| DisplayPorts-Version | 2.1 |
| Kopfhörerausgänge | 1 |
| Ethernet Schnittstellen Typ | Gigabit Ethernet |
| LAN-Controller | Realtek RTL8111H |
| Motherboard Chipsatz | Intel B860 |
| Audio-Chip | Realtek ALC897 |
| Audio Kanäle | 7.1 Kanäle |
| Produktfarbe | Dark brown |
| PC Gesundheitsüberwachung | Ventilator. Temperatur. Spannung. Water cooling |
| Komponente für | PC |
| Motherboardformfaktor | micro ATX |
| Motherboard Chipsatz Familie | Intel |
| Kühlung | Passiv |
| Energiequelle | ATX |
| Unterstützt Windows-Betriebssysteme | Windows 10 x64. Windows 11 x64 |
| PCI-Express x1 (Gen 3.x)-Anschlüsse | 1 |
| PCI Express x16-Steckplätze (Gen 4.x) | 1 |
| Anzahl der M.2 (M)-Steckplätze | 2 |
| 1. M.2 größte Schlüsselgröße | 2280 |
| 1. M.2 höchste PCI Express-Generation | 4.0 |
| 2. M.2 größte Schlüsselgröße | 2280 |
| 2. M.2 höchste PCI Express-Generation | 4.0 |
| BIOS-Typ | UEFI AMI |
| BIOS-Speichergröße | 256 Mbit |
| ACPI-Version | 5.0 |
| Desktop Management Interface (DMI) Version | 2.7 |
| Systemverwaltung BIOS (SMBIOS) Version | 2.7 |
| Ursprungsland | China |
| Menge pro Versandkarton | 1 Stück(e) |
| Batteriegewicht | 3 g |
| Lithiumgewicht pro Akku | 0.07 g |
| Anzahl Batteriezellen | 1 |
| Akku-/Batterietechnologie | Lithium-Manganese Dioxide (LiMnO2) |
| Akku-/Batterietyp | CR2032 |
| Verpackungsbreite | 265 mm |
| Verpackungstiefe | 265 mm |
| Verpackungshöhe | 54 mm |
| Paketgewicht | 972.4 g |
| Breite | 244 mm |
| Tiefe | 215 mm |
| Höhe | 35 mm |
| Mitgelieferte Software | Norton® Internet Security (OEM version)| LAN bandwidth management software |
| Gewicht | 890 g |
| Garantiezeit | 3 Jahr(e) |
