GS-4530X
LANCOM GS-4530X. Managed. L3. 2.5G Ethernet (100/1000/2500). Rack-Einbau. 1U
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
LANCOM GS-4530X. Switch-Typ: Managed. Switch-Ebene: L3. Basic Switching RJ-45 Ethernet Ports-Typ: 2.5G Ethernet (100/1000/2500). Anzahl der basisschaltenden RJ-45 Ethernet Ports: 30. Anzahl USB 2.0 Anschlüsse: 1. Konsolen-Port: RJ-45/Micro-USB. MAC-Adressentabelle: 32000 Eintragungen. Netzstandard: IEEE 802.1D. IEEE 802.1Q. IEEE 802.1Qav. IEEE 802.1Qbb. IEEE 802.1ab. IEEE 802.1ad. IEEE 802.1ak..... Rack-Einbau. Formfaktor: 1U
| Switch-Typ | Managed |
| Switch-Ebene | L3 |
| Feature | Rackmontageset |
| Anzahl der basisschaltenden RJ-45 Ethernet Ports | 30 |
| Basic Switching RJ-45 Ethernet Ports-Typ | 2.5G Ethernet (100/1000/2500) |
| Anzahl Gigabit Ethernet (Kupfer) Anschlüsse | 12 |
| Anzahl 2.5G Ethernet (Kupfer)-Ports | 12 |
| Menge Modul-Steckplätze SFP+ | 4 |
| Anzahl QSFP + Modulsteckplätze | 2 |
| Konsolen-Port | RJ-45/Micro-USB |
| Anzahl USB 2.0 Anschlüsse | 1 |
| Ethernet LAN Datentransferraten | 100.1000.2500 Mbit/s |
| Anzahl der VLANs | 4093 |
| Durchsatz | 324 Gbit/s |
| MAC-Adressentabelle | 32000 Eintragungen |
| Jumbo-Frames | 12288 |
| Datenpaket-Pufferspeicher | 4 MB |
| DHCP-Funktionen | DHCP client. DHCP relay. DHCP server. DHCP snooping |
| Autentifizierungstyp | RADIUS. TACACS+ |
| Formfaktor | 1U |
| Produktfarbe | Schwarz |
| Gehäusematerial | Metall |
| Belüftungssystem | Luftstrom von vorne nach hinten |
| Anzahl Lüfter | 3 Lüfter |
| Geräuschpegel | 50 dB |
| Energiequelle | AC |
| AC Eingangsspannung | 100 - 240 V |
| AC Eingangsfrequenz | 50/60 Hz |
| Stromverbrauch (max.) | 70 W |
| Betriebstemperatur | 0 - 40 °C |
| Temperaturbereich bei Lagerung | 0 - 50 °C |
| Relative Luftfeuchtigkeit in Betrieb | 10 - 90% |
| Wärmeableitung | 240 BTU/h |
| Breite | 442 mm |
| Tiefe | 373 mm |
| Höhe | 44 mm |
| Gewicht | 5.5 kg |
| Mitgelieferte Kabel | AC. Mikro-USB. Seriell |
| Zolltarifnummer (TARIC) | 85176200 |
| Ursprungsland | Taiwan |
