Intel Core i5-14600K LGA1700 14-Core Desktop Processor (Tray)
Intel Core i5-14600K 14-core desktop processor with 6 performance cores and 8 efficiency cores, 5.3GHz turbo, LGA1700 socket, 125W TDP, DDR4/DDR5 support, and integrated UHD Graphics 770.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| CPU (Processors) - Socket | Intel LGA1700 |
|---|---|
| CPU (Processors) - Processor Family | Intel Core i5 |
| CPU (Processors) - Cores | 14 |
| CPU (Processors) - Threads | 20 |
| CPU (Processors) - TDP | 121-150W |
| CPU (Processors) - Integrated Graphics | Yes (Integrated Graphics) |
| CPU (Processors) - Memory Support | DDR4 DDR5 |
| CPU (Processors) - Unlocked/Overclockable | Yes |
| CPU (Processors) - Cooler Included | No |
The Intel Core i5-14600K is a high-performance desktop processor based on the Intel 7 manufacturing process, featuring a hybrid architecture with 6 Performance cores (Raptor Cove) and 8 Efficiency cores (Gracemont). This 14th generation processor delivers 20 threads of processing power with a base frequency of 3.5GHz on P-cores and up to 5.3GHz turbo boost, making it suitable for gaming, content creation, and general computing tasks.
The processor includes 24MB of L3 cache and 20MB of L2 cache for improved performance. It supports dual-channel DDR4-3200 and DDR5-5600 memory up to 192GB maximum, with integrated Intel UHD Graphics 770 providing display outputs via DisplayPort 1.4a, HDMI 2.1, and eDP 1.4b. The 125W typical TDP (181W maximum turbo) ensures efficient power consumption, while the LGA1700 socket provides compatibility with Intel 600 and 700 series chipsets.
This tray version is designed for system integrators and OEM builds without retail packaging or included cooler. Performance benchmarks show approximately 3.9% multi-threaded improvement over the i5-13600K predecessor, with notable gains in compression and specialized workloads.
- 14 cores (6P+8E), 20 threads with hybrid architecture
- 5.3GHz maximum turbo frequency on performance cores
- 24MB L3 + 20MB L2 cache configuration
- Supports DDR4-3200 and DDR5-5600 memory
- Integrated Intel UHD Graphics 770 with 4-display support
- 125W typical TDP, 181W maximum turbo power
- LGA1700 socket for 600/700 series chipsets
- Intel Turbo Boost 2.0 technology included
| Processor Manufacturer | Intel |
| Processor Family | Intel Core i5 |
| Processor Model | i5-14600K |
| Processor Generation | 14th Gen (Raptor Lake) |
| Socket Type | LGA1700 |
| Total Cores | 14 (6 Performance + 8 Efficiency) |
| Total Threads | 20 |
| Performance Cores | 6 cores (Raptor Cove) |
| Efficiency Cores | 8 cores (Gracemont) |
| P-Core Base Frequency | 3.5 GHz |
| P-Core Turbo Frequency | 5.3 GHz |
| E-Core Base Frequency | 2.6 GHz |
| E-Core Turbo Frequency | 4.0 GHz |
| L1 Cache | P-Core: 6 x 32KB Instruction + 6 x 48KB Data; E-Core: 8 x 64KB Instruction + 8 x 32KB Data |
| L2 Cache | 20 MB (6 x 2MB P-Core + 2 x 4MB E-Core) |
| L3 Cache | 24 MB |
| Manufacturing Process | Intel 7 (10 nm) |
| Microarchitecture | Raptor Cove (P-Core), Gracemont (E-Core) |
| Typical TDP | 125 W |
| Maximum Turbo Power | 181 W |
| Processor Base Power | 125 W |
| Maximum Junction Temperature | 100°C |
| Instruction Set | 64-bit |
| Supported Instruction Sets | AVX 2.0, SSE4.1, SSE4.2 |
| Integrated Graphics | Intel UHD Graphics 770 |
| Graphics Base Frequency | 300 MHz |
| Graphics Maximum Frequency | 1550 MHz |
| Graphics Execution Units | 32 |
| Maximum Displays Supported | 4 |
| Graphics Output Interfaces | DisplayPort 1.4a, HDMI 2.1, eDP 1.4b |
| Maximum Resolution (DisplayPort) | 7680 x 4320 @ 60Hz |
| Maximum Resolution (HDMI) | 4096 x 2160 @ 60Hz |
| Maximum Resolution (eDP) | 5120 x 3200 @ 120Hz |
| DirectX Support | 12.0 |
| OpenGL Support | 4.5 |
| OpenCL Support | 3.0 |
| Memory Support | DDR4-3200, DDR5-5600 (ECC Supported) |
| Maximum Memory | 192 GB |
| Memory Channels | Dual-Channel |
| Memory Bandwidth | 89.6 GB/s |
| PCI Express Lanes | 20 (16 Gen5 + 4 Gen4) |
| PCI Express Configurations | 1x16+1x4 or 2x8+1x4 |
| DMI Revision | 4.0 |
| Maximum DMI Lanes | 8 |
| Turbo Boost Technology | Intel Turbo Boost 2.0 |
| Thermal Solution Specification | PCG 2020A |
| Processor Package Size | 45 x 37.5 mm |
| Packaging Type | Tray |
| Cooler Included | No |
| Chipset Compatibility | Intel 600 Series, Intel 700 Series |
| Market Segment | Desktop |
| Use Cases | Workstation, PC/Client/Tablet, Gaming |
| Launch Date | Q4 2023 |
| Product Status | Launched |
| ARK Product ID | 236799 |
| Unlocked Multiplier | Yes (K-series) |
| Overclocking Support | Yes |
