NETGEAR GS110TP-300EUS - 8-Port Gigabit PoE Managed Switch (L2/L3/L4), 2x SFP, 54V DC
Managed 8-port Gigabit PoE switch (GS110TP-300EUS) with L2/L3/L4 features, 2 SFP slots, 8x 10/100/1000 RJ-45, 8000 MAC entries, 20 Gbps switching capacity.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| Network Switches - Type | Managed L3 |
|---|---|
| Network Switches - Ports | 8 |
| Network Switches - Port Speed | Gigabit (10/100/1000) |
NETGEAR GS110TP. Switch type: Managed. Switch layer: L2/L3/L4. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8000 entries. Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3ab. IEEE 802.3af. IEEE 802.3i. IEEE 802.3u. IEEE 802.3x. IEEE 802.3z. DC input voltage: 54 V. Power over Ethernet (PoE)
| Switch type | Managed |
| Switch layer | L2/L3/L4 |
| Feature | Manual |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| SFP module slots quantity | 2 |
| Networking standards | IEEE 802.3ab. IEEE 802.3af. IEEE 802.3i. IEEE 802.3u. IEEE 802.3x. IEEE 802.3z |
| Copper ethernet cabling technology | 10BASE-T. 100BASE-TX. 1000BASE-T |
| Number of VLANs | 64 |
| Switching capacity | 20 Gbit/s |
| MAC address table | 8000 entries |
| Packet buffer memory | 0.5 MB |
| DHCP features | DHCP client |
| Access Control List (ACL) IPv6 entries | 100 |
| Security algorithms | 802.1x RADIUS |
| IPv4 multicast entries | 32 |
| Number of multicast groups filtered | 256 |
| Management protocols | SNMP |
| Switching protocols | SNMP |
| Data link protocols | Ethernet. Fast Ethernet. Gigabit Ethernet |
| Supported network protocols | HTTP. HTTPS |
| Product colour | Grey |
| LED indicators | Activity. LAN. Link. PoE. Power. Speed |
| Processor frequency | 500 MHz |
| Memory type | RAM |
| Internal memory | 128 MB |
| Flash memory | 32 MB |
| Mean time between failures (MTBF) | 1200041 h |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| DC input voltage | 54 V |
| Input current | 1.25 A |
| Power consumption (max) | 15.1 W |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Power over Ethernet (PoE) power per port | 55 W |
| Total Power over Ethernet (PoE) budget | 69.5 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
| Heat dissipation | 237.38 BTU/h |
| Width | 236 mm |
| Depth | 101 mm |
| Height | 27 mm |
| Weight | 610 g |
| Package type | Box |
| Package width | 161 mm |
| Package depth | 267 mm |
| Package height | 86 mm |
| Package weight | 1.49 kg |
| Certification | CE. FCC. VCCI Class B. C-Tick |
| Master (outer) case width | 274 mm |
| Master (outer) case length | 350 mm |
| Master (outer) case height | 309 mm |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case gross weight | 9.73 kg |
| Products per master (outer) case | 6 pc(s) |
