Cougar MX230 RGB Mid-Tower PC Case Black – 400mm GPU, 10 Fans Max (Boxed)
Cougar MX230 RGB is an airflow-focused mid-tower case with full metal mesh front panel, 4 preinstalled ARGB fans, porous PSU shroud for 3 extra fans, up to 10 fans total, 400mm GPU support, and USB-C 10Gbps I/O.
Please Note
The website is currently being actively developed, you are welcome to place the order and in 99% of the cases your order will be processed as usual, but in some cases there may be a delay or the price may change. We will notify you if there are any issues.
Discontinued
This item was discontinued and currently is not available for order on our website. The item may become available soon. Please contact us if you need more information regarding the upcoming arrivals.
| PC Cases - Motherboard Support | ATX EATX Micro ATX Mini ITX |
|---|---|
| PC Cases - Radiator Support | 120 mm 140 mm 240 mm 280 mm 360 mm |
| PC Cases - Included Fans | 4+ |
| PC Cases - Front I/O | Audio Jacks USB A USB C USB C Gen2 |
| PC Cases - GPU Orientation | Horizontal |
| PC Cases - Form Factor | Mid Tower |
| PC Cases - Max GPU Length | 361–400 mm |
| PC Cases - Color | Black |
| PC Cases - CPU Cooler Clearance | 166-170 mm |
The Cougar MX230 RGB is a high-performance mid-tower PC case engineered around an airflow-first philosophy. Featuring a full metal mesh front panel that doubles as an integrated dust filter, the case prioritizes thermals and component cooling. The innovative porous PSU shroud supports three 120mm fans, creating a vertical thermal column for direct airflow to critical components while allowing optimal cable management.
Out of the box, it includes four preinstalled ARGB fans (three 120mm front intake, one 120mm rear exhaust) and supports up to 10 fans total. Compatible with E-ATX motherboards, it fits GPUs up to 400mm, CPU coolers to 170mm, PSUs to 200mm, and 360mm top radiators. Front I/O offers USB 3.2 Gen 2 Type-C (10Gbps), two USB 3.0 Type-A, and audio jack. Tool-less front panel and integrated ARGB controller with motherboard sync enhance usability.
Available in black, it supports 2×3.5-inch HDDs or 1+1 2.5-inch SSDs with 7 expansion slots. Dimensions: 220×475×445mm; weight: 5.8kg unboxed, 6.9kg boxed.
- All-metal front mesh panel with integrated dust filter and tool-less removal
- Preinstalled: 3×120mm ARGB front + 1×120mm ARGB rear
- Porous PSU shroud: up to 3×120mm fans
- Max 10 fans; 360mm radiator top support
- Motherboard: E-ATX/ATX/Micro ATX/Mini ITX
- GPU: 400mm | CPU cooler: 170mm | PSU: 200mm
- I/O: USB 3.2 Gen2 C, 2×USB 3.0 A, audio
- Storage: 2×3.5-inch or 1+1 2.5-inch
- Integrated ARGB hub with MB sync
| Case Form Factor | Mid Tower |
| Motherboard Support | Mini ITX, Micro ATX, ATX, E-ATX |
| Dimensions (W×H×D) | 220×475×445 mm (8.7×18.7×17.5 in) |
| Weight (Unboxed) | 5.8 kg |
| Weight (Boxed) | 6.9 kg |
| Front Panel | All-metal mesh with integrated dust filter |
| Preinstalled Fans | 3×120mm ARGB front intake + 1×120mm ARGB rear exhaust |
| Maximum Fan Capacity | 10 fans total |
| PSU Shroud | Porous design supporting up to 3×120mm fans |
| Radiator Support | 360mm (top), 240mm or 280mm (front), 120mm or 140mm (rear) |
| Maximum GPU Length | 400 mm (15.7 in) |
| Maximum CPU Cooler Height | 170 mm (6.7 in) |
| Maximum PSU Length | 200 mm (7.9 in) |
| Storage Bays | 2×3.5-inch HDD or 1+1 2.5-inch SSD (convertible) |
| Expansion Slots | 7 slots |
| Front I/O Ports | 1×USB 3.2 Gen 2 Type-C (10Gbps), 2×USB 3.0 Type-A, 1×4-pole audio jack |
| RGB Controller | Integrated ARGB hub with motherboard sync capability |
| Color Options | Black, White |
| EAN Code (Black) | 4711649770587 |
| UPC Code (Black) | 810201290250 |
| Manufacturer Part Number | 382PC80.0001 |
